316不锈钢网是采用SUS316不锈钢丝编制而晶笑压赶输成，316不锈钢网编织工艺有:平纹、斜纹、密纹编织。
- 中文名称 316不锈钢网
- 外文名称 316 stainless steel wire mesh
- 材质 316不锈钢丝
- 商家 安平县思迈丝网制品有限公司
优点
来自18Cr-12Ni-2.5Mo因添加M接在逐久状模员o，故其耐蚀性、耐大气腐蚀算越性和高温强度特别好，可在苛酷的条件下使用，在盐水、硫磺水或在卤盐中比其它的铬镍不 锈钢更不易被腐蚀。耐腐蚀性能优于304不锈钢网，在浆和造纸的生产过程中具有良好的耐腐蚀360百科的性能。而且316治岁不锈钢网相比304不锈钢网更线龙井加耐海洋和侵蚀性工业大气指次的侵蚀.
316不锈钢网 规格
316不锈钢网的宽度为0.914米、1米、1.22诗准武波丝米、1.3米、1.4米、1.5米、1.6米、2米、2.5米。目数为20目-500目，特殊规格可以定做。
包装
产品从内而外的包装顺序为:先包装防潮纸-其次包装防潮膜-再包装气垫膜-然后装入硬纸筒-包装完毕后相同规格装入木箱防止产品在运输过程当中受潮受撞击。
用途
316不锈钢网主要用于酸、碱环境条件下筛分和过滤，在矿业、化工、食品、医药等行业也有应用。
不锈钢网 包装要求
产品外层必须按防潮纸-防潮膜-气垫膜-硬纸筒低结娘年流担令调史-木箱顺序包装防止产品在运来自输过程当中受潮受撞击在夫合。
目数与孔径
目数 | 丝径 | 孔径 | 开孔面积 | 网重(磅)/100平方英尺 | ||
英寸 | 毫米 | 英寸 | 毫米 | |||
1x1 | .080 | 2.03 | .920 | 23.37 | 84.6 | 41.1 |
2X2 | .063 | 1.60 | .437 | 11.10 | 76.4 | 51.2 |
3X3 | .054 | 1360百科.37 | .279 | 月喜自圆结 7.09 | 70.1 | 56.7 |
4X4 | .063 | 1.60 | .187 | 4.75 | 56.0 | 104.8 |
4X4 | 联缺基校感查胞老 .047 | 1展认标.19 | .203 | 5.16 | 65.9 | 57.6 |
5X5 | .041 | 1.冷失首04 | .159 | 4.04 | 63南医密着酸叶.2 | 54.9 |
6X6 | .035 | .89 | .132 | 3.35 | 62.北置并7 | 48.1 |
8X8 | .028 | .71 | .097 | 2.46 | 60.2 | 41.1 |
10X10 | .025 | .64 | .075 | 1.91 | 56.溶优但科他封3 | 41.2 |
10X10 | .020 | .51 | .080 | 2.03 | 64.0 | 26.1 |
12X12 | .023 | .584 | .060 | 1.52 | 51.8 | 42.2 |
12X12 | .020 | 径远按视目致坐他州减直.508 | .06命距知附取十3 | 1.60 | 57.2 | 31.6 |
14X14 | .023 | .584 | .048 | 1.22 | 45.2 | 49.8 |
14X14 | .020 | .508 | .051 | 1.30 | 51.0 | 37.2 |
16X16 | .018 | .457 | .0445 | 成攻加我卫均认杨封船 1.13 | 50.7 | 34.5 |
18X18 | .017 | .432 | 微创它晶章.0386 | .98 | 4胜8.3 | 34.8 |
20X20 | .020 | .508 | .0300 | .76 | 36.0 | 55.2 |
20X20 | .016 | .406 | .034选重0 | .86 | 46.2 | 34.4 |
24X考印24 | .014 | .356 | .0277 | 获艺此烟进房温展城停够 .70 | 44.2 | 31.8 |
30X30 | .013 | .330 | .0203 | .52 | 37量意食始还声.1 | 34.8 |
30X30 | .012 | .305 | .0213 | .54 | 40.8 | 29.4 |
30X30 | .009 | .229 | .0243 | .62 | 53.1 | 16.1 |
35X35 | .011 | .279 | .0176 | .45 | 37.9 | 29.0 |
40X40 | .010 | .254 | .0150 | .38 | 36.0 | 27.6 |
50X50 | .009 | .229 | .0110 | .28 | 30.3 | 28.4 |
50X50 | .008 | .203 | .0120 | .31 | 36.0 | 22.1 |
60X60 | .0075 | .191 | .0092 | .23 | 30.5 | 23.7 |
60X60 | .007 | .178 | .0097 | .25 | 33.9 | 20.4 |
70X70 | .0065 | .165 | .0078 | .20 | 29.8 | 20.8 |
80X80 | .0065 | .165 | .0060 | .15 | 23.0 | 23.2 |
80X80 | .0055 | .140 | .0070 | .18 | 31.4 | 16.9 |
90X90 | .005 | .127 | .0061 | .16 | 30.1 | 15.8 |
100X100 | .0045 | .114 | .0055 | .14 | 30.3 | 14.2 |
100X100 | .004 | .102 | .0060 | .15 | 36.0 | 11.0 |
100X100 | .0035 | .089 | .0065 | .17 | 42.3 | 8.3 |
110X110 | .0040 | .1016 | .0051 | .1295 | 30.7 | 12.4 |
120X120 | .0037 | .0940 | .0064 | .1168 | 30.7 | 11.6 |
150X150 | .0026 | .0660 | .0041 | .1041 | 37.4 | 7.1 |
160X160 | .0025 | .0635 | .0038 | .0965 | 36.4 | 5.94 |
180X180 | .0023 | .0584 | .0033 | .0838 | 34.7 | 6.7 |
200X200 | .0021 | .0533 | .0029 | .0737 | 33.6 | 6.2 |
250X250 | .0016 | .0406 | .0024 | .0610 | 36.0 | 4.4 |
270X270 | .0016 | .0406 | .0021 | .0533 | 32.2 | 4.7 |
300X300 | .0051 | .0381 | .0018 | .0457 | 29.7 | 3.04 |
325X325 | .0014 | .0356 | .0017 | .0432 | 30.0 | 4.40 |
400X400 | .0010 | .0254 | .0015 | .370 | 36.0 | 3.3 |
500X500 | .0010 | .0254 | .0010 | .0254 | 25.0 | 3.8 |
635X635 | .0008 | .0203 | .0008 | .0203 | 25.0 | 2.63 |
